The Exam Room Counter Door enables healthcare and institutional facilities to continuously use the same space for both medical and behavioral patients. By employing this door, facilities can create a multi-purpose room, saving costs and resources while ensuring necessary security for patients. For commercial use only.

Exam Room Counter Door

The Exam Room Counter Door enables healthcare and institutional facilities to continuously use the same space for both medical and behavioral patients.

Request A Quote Get Architectural Support

Enter your zip code to find your local dealer

Zip Code

CESC15

Aesthetics

SpectraShield™ Powder Coating – It is a Polyester finish in more than 180 colors offering durability, aesthetics, superior finish life and cost effectiveness.

Omni Powder Coat – Allows you to match your rolling steel doors with select sectional doors to create a unified look. Available in:

Commercial Tan
Commercial Gray
Charcoal
Standard White
Chocolate Brown
Black

Safety & Protection

Sensing Edge - Designed with a flexible black rubber TPE material, our sensing edge has two fins that form to variations in the floor on both the interior and exterior of your door or grille. This ensures a secure seal without requiring you to over set the bottom door limit.

Usage

Our Exam Room Counter Doors are constructed for daily use.

Standard Materials and Finishes

Counter-Balance Shaft – Made of steel, supports curtain and contains torsion springs for assisting operation

Brackets – Steel with powder coating to match curtain

Tubes & Guides – Two piece steel guides attached to tubes that are recessed into drywall

Curtain - Interlocking roll-formed flat-faced slats made of Galvanized steel with GalvaNex™ polyester enamel finish in gray, tan or white.

End Locks - Riveted to the end of each slat, they are designed to ensure that the curtain is held within the guides in the event of impact.

Bottom Bar - Single angle flat bottom bar in steel with powder coating to match curtain creates a smooth transition.

Model

BIM

Shop Drawing

Specs

Installation Manual

Warranty
